니토 WA-5000 마그네틱드릴

제품이미지

7 베어링 슬리브

266898-7

1,100

총 90개

이미지 또는 부품명 클릭시 상세정보 조회

0 / 0

이미지	항목번호	부품번호	부품명	소요량	판매가	장바구니 담기

1	9340873	DRILL MOTOR ASSY 220-240V	1	1,265,000	품절
2	9138737	SIDE HANDLE ASSY	1	20,350
3	9138856	OIL RING SUB ASSY	1	137,500
4	9138741	HOSE NIPPLE	2	4,400
5	9138515	SEAL PACKING	2	2,200
6	9138532	OIL SEAL GD38484	2	20,900
8	9138505	WASHER(38.5541)	2	15,400
11	9138818	ARBOR BODY ASSY	1	253,000	품절
15	9138764	PILOT SPACER	1	22,000
16	9138765	SPACER(10.5X19.5)	1	4,400	품절
17	9138772	RETAINING RING RTW-19	2	1,650	품절
18	9138757	와셔 ASSY	1	7,700
19	9138817	SPRING(0.8X12X31)	1	6,050	품절
20	9138499	PUSH RING ASS'Y	1	24,200	품절
21	9138711	TWIST SPRING	1	8,800	품절
22	9138712	SLEEVE	1	47,300
23	9138743	RETAINING RING C-28	1	5,500
25	9340943	DROPPER PIPE	1	10,450	품절
26	9340942	DROPPER PACKING	2	7,700
27	9340880	DROPPER NIPPLE	2	8,250
28	9340879	DROPPER PLATE	1	7,700	품절
31	9100446	SLIDE BOARD	1	214,500	품절
35	9138539	RACK	1	75,900	품절
36	9138701	SLIDE PLATE	1	22,000
37	9138750	GIB	1	6,600
38	9138702	BRACKET ASS'Y	1	110,000	품절
39	9138751	HEX.SOCK.HD.CAP8X30	3	2,200
40	9138724	SPUR GEAR 1X5X26	1	20,350
41	9138749	와셔 12.2X28X1	1	2,200
42	9138723	SPUR GEAR 1X5X14X29	1	27,500
48	9138731	SHAFT	2	19,250
49	9138861	BODY SUB ASSY	1	484,000	품절
53	9138853	블레이드(날)	1	38,500	품절
56	9138812	SQUARE POLE ASS'Y220-240V	1	605,000
61	9202163	SLIDE DETECTION DEVICE	1	110,000	품절
66	9340872	SET SCREW	1	5,500	품절
69	9138808	CONTROL BOARD ASSY	1	418,000
71	9138824	SWITC SW3 ASSY	1	35,200
72	9138823	SWITC SW2 ASSY	1	35,200
73	9138754	PACKING BODY	1	5,500
74	9138811	SWITCH PLATE	1	38,500
75	9138733	ROCKER S/W 6.3 1935.31	1	30,800
78	9138821	WATERPROOFING CAP BLACK	1	15,950	품절
79	9138822	WATERPROOFING CAP RED	1	18,700	품절
84	9138721	GEAR SHAFT	1	170,500	품절
85	9138756	HANDLE STEM	1	165,000	품절
87	9138725	ROD HANDLE	3	25,850
89	9138859	SPRING	3	9,350
96	9138758	C.CONNECTOR3217 W/NUT	2	17,600	품절
100	9138722	SPUR GEAR 1X88	1	93,500
103	9138746	GEARED MOTOR	1	308,000	품절
104	9138734	SPUR GEAR 1X23	1	13,200	품절
106	9138747	GEAR BOX	1	154,000	품절
107	9341020	HEX. SOCKET BOLT 4X35	8	2,200
108	9138865	RETAINING RING GV-16	2	2,200	품절
111	9138899	COVER PLATE	1	5,500
112	9138742	P-VALVE PT1/8	1	16,500
114	9138715	RUBBER CAP	1	3,300
115	9138708	OIL TANK	1	18,700	품절
116	9138755	RUBBER PLUG	1	2,750
201	9138720	CORD PROTECTOR	1	14,850
203	9341018	STATOR SCREW 4.8X45	4	2,200
204	9138717	캡	1	23,100	품절
205	9138719	MOTOR HOUSING	1	77,000
206	9138706	브러시홀더 아세이	2	18,700	품절
207	9138704	카본브러시	1	25,300
211	9138819	CONDENSER	1	12,650
212	9138801	STATOR ASSY(230V)	1	165,000
214	9391019	19B30906016 BOLT,FLANGE,M6-16	2	550	품절
215	9138730	AIR GUIDING RING	1	17,600
216	9138718	O-RING(22X2.5)	1	2,200
217	2417980	BALL BEARING(608ZZ/TP,LFK)	1	2,200
218	9138802	아마추어 회전자	1	429,000
219	9138771	EXTERNAL RETAINING RING C-28	1	1,650
220	2417369	볼베어링(6001ZZCMM)	1	3,300
222	9138816	BEARING BRACLET ASSY	1	135,300
224	9138810	GEAR BLOCK 34/40Z	1	126,500
225	9138806	PIINION SHAFT 13Z	1	82,500
226	9138814	KEY A5X5X28	1	3,850	품절
227	9138729	GREASE CHAMBER	1	9,350
228	9138820	INTERMEDIATE GEAR 34Z	1	52,800
229	9138809	PINION SHAFT 11/17Z	1	88,000
231	9138805	SPINDLE GEAR 45Z	1	115,500
232	9138864	FITTING WASHER,WA-3500	1	2,200
234	9138858	COUPLING BOLT ASSY	1	63,800
237	9138815	GEAR CASE ASSY	1	159,500
238	9138800	GEAR CHANGER ASSY	1	10,450
240	9341225	PT-SCREW 5.0 X 50	1	2,750	품절
241	9138813	KEY A5X5X12	1	3,850	품절
242	9138804	스핀들	1	88,000	품절
