보쉬 GKS18V-57G 분해도 (3601FA21B0)

제품이미지

7 베어링 슬리브

266898-7

1,100

총 54개

이미지 또는 부품명 클릭시 상세정보 조회

0 / 0

이미지	항목번호	부품번호	부품명	소요량	판매가	장바구니 담기

1	1619P11863	Motor Housing	1	6,930
2	2610942109	Pole housing	1	16,390
4	1619P11912	Electronics Module	1	44,880
16	2610934990	Brush Holder	2	2,200
21	1619P14306	Spiral Spring	2	2,530
22	1619P11879	Handle	1	14,190	품절
24	1619P11877	Baffle	1	1,980
26	1619P11913	End cap	1	3,080	품절
27	1619P01127	Rubber Ring	1	1,210
33	1619P11883	Key Holder	1	1,980
34	1619P06225	Cap	1	1,210
38	1619P11886	Guide Bracket	1	2,860
39	1619P01642	Compression Spring	1	1,210
50	1619P11885	Inner Disc	1	3,740	품절
51	1619P11884	Locking washer	1	3,080
52	1619P06232	Screw	1	1,650
54	1619P06238	Locking washer	1	1,210
57	F000640007	O-Ring	1	1,210
58	1619P11900	Lower guard	1	14,190
60	1619P10133	Extension Spring	1	1,650
61	1619P06236	Bumper	1	1,650
62	2610935251	Compression Spring	1	1,430
67	1619P11929	Screw	1	1,650
69	1619P11908	Base Plate	1	40,480
70	1600210050	O-Ring	1	1,210
71	1600A00XX2	Bridge	1	24,200
72	2604690055	Compression Spring	1	1,210	품절
75	1619P00220	Torx Oval-Head Screw	4	1,210
76	1619P01636	Wing Nut	2	1,430
77	2916011014	Plain Washer	1	1,210
78	1619P09218	Round-Head Bolt	2	1,430
79	1619P11917	Switch Button	1	2,200
80	2610924368	Lever	1	1,980
81	1619P01449	Rubber Buffer	2	1,430
82	1619P07620	Adjustment rod	1	1,650
83	1619X01792	Spring	1	1,210
84	1619P17212	Cover	1	1,980
85	1619P01618	Wing Screw	1	1,210
87	2603490022	Screw	10	1,210
89	1619P11927	Hinge Bracket	1	2,530
90	1619P11926	Hinge Bracket	1	3,960
93	1603435068	Thread-forming tap. Screw	6	1,430
94	1619P06246	Screw	1	1,650
95	2610925864	Screw	3	1,210
96	2610924687	Countersunk-Head Screw	2	1,210
651	1617S020T1	Battery Pack	1	60,610	품절
653	2607225933	Charger	1	102,190
654	2610364015	Hexagon Socket Screw Key	1	2,530
655	1619X01612	Mitre Fence	1	6,930
656	1619P11691	Adapter	1	1,980	품절
803	1619P11898	Armature set	1	40,480
810	2610943623	Carbon-Brush Set	1	8,030
823	1619P11904	Upper guard	1	24,200	품절
853	1619P11906	Bearing Flange	1	18,480	품절
