계양 KCD-10 습식코어드릴 부품

제품이미지

7 베어링 슬리브

266898-7

1,100

총 128개

이미지 또는 부품명 클릭시 상세정보 조회

0 / 0

이미지	항목번호	부품번호	부품명	소요량	판매가	장바구니 담기

1-1	9424000	GEAR COVER	1	126,500	품절
1-2	9424001	Inner Cover	1	95,700	품절
1-3	9423841	HOUSING	1	64,900	품절
1-4	9424002	CLAMP BODY	1	165,000
1-5	9424003	Body Cover	1	42,900	품절
1-7	9424004	Water Cock	1	26,400	품절
1-8	9423845	Brush Holder	2	7,700	품절
1-9	9423846	아마추어 회전자	1	101,200
1-10	9424005	Final Gear (H)	1	60,500	품절
1-11	9424006	3RD Pinion (H)	1	55,000	품절
1-12	9424007	Metal Bush (A)	1	6,600	품절
1-13	9424008	Metal Bush (B)	1	6,600	품절
1-14	9423850	Insulation Paper	1	1,100	품절
1-15	9423852	PUSHER PLATE	5	2,200	품절
1-16	9423853	Cord Ass'y	1	18,700	품절
1-17	9424009	Cable Gland	1	7,700	품절
1-18	9423855	Controller Ass'y	1	44,000	품절
1-19	9423856	+Pan HD Tapping Screw	2	1,100	품절
1-20	9423857	STATOR ASSY	1	40,700
1-21	9423858	Spring Washer	2	1,100	품절
1-22	9424010	Oil Seal (A)	1	3,850	품절
1-23	9424011	Ball Bearing(6202ZZ)	1	9,350	품절
1-24	9423882	+Truss HD M/C Screw	2	1,100	품절
1-25	9423861	KNOB (A)	2	4,950
1-26	9424012	SLIDE PLATE	8	2,200
1-27	9423863	SWITCH COVER	1	8,250
1-28	9423859	+Pan HD M/C Screw	2	1,100	품절
1-29	9423916	+Pan HD M/C Screw	4	1,100	품절
1-30	9423866	Body Handle	1	16,500	품절
1-33	9424013	Spindle	1	132,000	품절
1-34	9423880	Spring Washer	8	1,100	품절
1-35	9424014	Final Gear (L)	1	73,700	품절
1-36	9424015	First Gear	1	44,000	품절
1-37	9424016	Second Pinion	1	42,900	품절
1-38	9424017	3RD Pinion (L)	1	60,500	품절
1-39	9423872	Collar	1	4,950	품절
1-40	9424018	Disc	2	10,450	품절
1-41	9424019	Second Gear	1	57,200	품절
1-42	9424020	Nut Collar	1	9,350	품절
1-43	9423876	U-Nut	1	7,700	품절
1-44	9423877	METAL BUSH (C)	1	4,950
1-46	9423851	Inner Housing	1	30,800	품절
1-48	9424021	Spring Washer	3	1,100	품절
1-49	9423881	Cock Valve	1	17,600	품절
1-51	9424022	Spring (A)	1	2,200	품절
1-52	9423883	Spring (B)	1	2,200	품절
1-53	9423884	Spring (C)	2	4,950	품절
1-54	9424023	Shaft Gear	1	27,500	품절
1-55	9423886	Clamp Handle Boss	1	27,500	품절
1-56	9423887	Clamp Handle Bar	1	13,200	품절
1-58	9424024	Wrench Bolt	4	1,650	품절
1-59	9424025	O-Ring (A)	2	1,650	품절
1-60	9424026	Retaining Ring (D)	1	2,200	품절
1-61	9424027	Ball Bearing(6006DU)	2	20,900	품절
1-62	9424028	Oil Seal (B)	1	4,950	품절
1-63	9424029	Retaining Ring (A)	1	1,100	품절
1-64	9424030	Retaining Ring (B)	1	1,100	품절
1-65	9424031	Retaining Ring (C)	1	1,100	품절
1-66	9423896	Ball Bearing	3	9,350	품절
1-67	9424032	Retaining Ring (E)	1	2,200	품절
1-68	9423897	Feather Key	1	2,200	품절
1-69	9424033	Ball Bearing(6002ZZ)	2	8,250	품절
1-70	9424034	Disc Spring	1	3,850	품절
1-71	9423900	Ball Bearing	1	15,400	품절
1-72	9423901	Ball Bearing	1	16,500	품절
1-73	9423902	Carbon Brush	2	3,850	품절
1-74	9423903	Brush Cap	2	1,100	품절
1-75	9424036	Switch	1	81,400	품절
1-76	9423905	Hex Bolt	6	1,100	품절
1-77	9423906	Ball Bearing	4	6,600	품절
1-78	9424038	Retaining Ring (F)	2	1,100	품절
1-80	9423908	+Flat HD M/C Screw	16	1,100	품절
1-81	9423917	Stop Plate	2	1,100	품절
1-82	9423909	Set Screw	2	1,100	품절
1-83	9423910	Wrench Bolt	4	1,100	품절
1-84	9423911	Spring Washer	6	1,100	품절
1-85	9423912	Spring Washer	8	1,100	품절
1-86	9424040	Hex Nut	4	1,100	품절
1-87	9424042	Set Screw	4	1,100	품절
1-88	9423915	Knob (B)	1	4,950	품절
1-90	9423849	Lock Ass'y	1	15,400	품절
1-92	9423879	Plan Washer	8	1,100	품절
1-95	9424044	+Pan HD M/C Screw	3	1,100	품절
1-97	9424046	Wrench Bolt	4	1,100	품절
1-98	9424048	Feather Key	1	5,500	품절
1-100	9423920	Spanner	1	18,700	품절
1-101	9424050	Tool Bag	1	18,700	품절
1-102	9424052	L-Wrench	1	1,650	품절
1-103	9423925	L-Wrench	1	1,100	품절
1-104	9423927	L-Wrench	1	1,100	품절
1-105	9424054	Wrench Bolt	2	1,650	품절
1-108	9424058	Packing Box (A)	1	46,200	품절
1-114	9424060	PLATE	1	7,700
1-115	9424406	Lever Plate Ass'y	1	58,300	품절
1-116	9424407	O-RING (B)	1	1,650
1-117	9424063	Slip Washer (A)	1	2,750	품절
1-118	9424065	Slip Washer (B)	1	2,750	품절
1-119	9424067	Slip Washer (C)	2	2,750	품절
1-120	9424069	Change Plate	1	77,000	품절
1-121	9424071	Knob (C)	1	14,300
1-122	9424073	Lever Bolt	1	14,300
1-123	9424075	Change Speed Label	1	1,100	품절
1-124	9423847	Switch Cover (A)	1	7,150	품절
1-125	9423848	+Pan HD M/C Screw	2	1,100	품절
1-127	9424077	Shaft Gear (A)	1	40,700	품절
1-128	9424079	Shaft Gear (B)	1	33,000	품절
1-129	9424081	Feather Key	1	3,300	품절
1-130	9423864	End Cover	1	13,200	품절
1-140	9423942	Level Gauge	1	8,250	품절
1-141	9423865	+Pan HD M/C Screw	1	1,100	품절
1-142	9423940	Wrench Bolt	4	1,100	품절
1-143	9423944	Plain Washer	4	1,100	품절
1-144	9424083	Slip Washer (D)	1	3,300	품절
1-145	9424085	O-Type Ring	1	1,100	품절
1-146	9424087	Sleeve Terminal	8	1,650	품절
2-6	9424091	Base	1	132,000	품절
2-31	9424093	Stand Pipe	1	110,000	품절
2-32	9424408	Stand Pipe Cap	1	27,500	품절
2-57	9424409	Lack Gear	1	84,700	품절
2-79	9423958	Spring Pin	2	1,100	품절
2-89	9423960	Wrench Bolt	4	1,100	품절
2-91	9423972	Wrench Bolt	1	2,200	품절
2-92	9424410	Wrench Bolt	1	2,200	품절
2-93	9423962	Hex Nut (2종)	4	2,200	품절
2-94	9423965	Hex Bolt	4	2,200	품절
2-109	9424411	Packing Box (B)	1	24,200	품절
2-112	9423966	Ruler	1	2,750	품절
2-150	9424089	Stand Ass'y	1	374,000	품절
